NAMUR solenoid valves

Parameter Value
Valve types 5/2 mono- and bi-stable
Mounting standard Namur
Connection ports M5×0.8, 1/8″, 1/4″, 3/8″
Required air filtration 40 μm
Flow rates [Nl/min] 310–1680
Operating pressure [MPa] 0.15–0.80 MPa (22–116 psi)
Operating temperature -20–70 °C (-40–70 °C low-temperature version) (-4–158 °F / -40–158 °F)
Switching time open/close at 0.5 MPa (73 psi) [ms] ≤ 50/50
Switching frequency [Hz] 5
Electrical connection DIN socket with diode, 0.5 m cable
Supply voltages AC 220 V, DC 24 V, AC 110 V, AC 24 V, DC 12 V
